High-Efficiency 1.1KW 1.5HP 87/61mm Three-Phase Aluminium Electric Induction Motor 50Hz 24mm Hollow Shaft Waterproof Hawk Pump
無料サンプルとクーポンについては、私に連絡してください。
ワッツアップ:0086 18588475571
微信: 0086 18588475571
スカイプ: sales10@aixton.com
ご不明な点がございましたら、24 時間対応のオンライン ヘルプをご利用ください。
x商品の詳細
| アシンクロン速度 | 1400rpm | 断熱クラス | f |
|---|---|---|---|
| 囲い | IP55 | 周囲温度 | 40°C |
| フレームサイズ | 100 | 保護クラス | IP55 |
| 色 | カスタマイズ可能 | 力 | 1.5hp/1.1kw |
| 義務 | S1(連続) | トルク | 高い |
| 高度 | ≤1000m | 定格頻度 | 50Hz/60Hz |
| 取り付けタイプ | 取付けられるフィート | ||
| ハイライト | 7.5KW Hollow Shaft Motor,10HP Three-Phase Induction Motor,60Hz Frequency AC Induction Motor |
||
あなたはあなたが必要とする製品にチェックを入れて、メッセージボードで私たちと通信することができます。
製品の説明
Company Profile
Established in 2006, Fuan Zhongzhi Pump Co., Ltd. The trademark registration "ZOZHI" has made it a modernized private enterprise. It is specialized in scientific research, production, sales and service, manufacturing various types of pumps, such as peripheral, centrifugal, jet, deep well, sewage pump, etc., as well as high-efficiency AC motors, alternators and diesel generators.
Zhongzhi pumps are widely utilized in shallow and deep well pumping, pipeline boosting, water tower boosting, garden irrigation, agricultural irrigation, and aquaculture drainage, etc.
Zhongzhi motors can be employed for general driving purposes, such as household appliances, pumps, fans, and recording meters, etc.
Zhongzhi generators are fully applied in communication systems, data centers, mining, power, highways, engineering companies, financial systems, hotels, railways, military, airports, commercial buildings, hospitals, factories, etc. We have established a global service system in collaboration with strategic partners. Our production of generator sets has become the backup power choice for the largest number of hotels, buildings, and industrial and mining enterprises.
Zhongzhi products are popular in over 70 countries including Europe, America, the Middle East, Africa, Southeast Asia, and others.
Motivated by our slogan "Solidarity, Exploration, Honest, Faith", we strive to become the global leader in providing comprehensive and reliable solutions to make this world a better place to live in.
1.1KW 1.5HP Three-Phase Hollow Shaft Motor 60Hz Frequency 1450RPM
This industrial-grade 1.5HP AC induction motor (1.1KW) delivers reliable, high-torque performance for demanding applications. Engineered with a precise 1400RPM speed and standardized three-phase 380V/50Hz power supply, it features an integrated 24mm hollow shaft for direct-drive solutions in water pumps, gearboxes, conveyors, and various machinery requiring efficient power transmission.
Key Specifications
| Brand Name | ZOZHI |
|---|---|
| Type | Asynchronous Motor |
| Phase | Three phase |
| Frequency | 50Hz/60Hz |
| Efficiency | IE 1 |
| Protection Class | IP55 |
| Certification | CCC/CE/ISO9001 |
| Housing | Aluminium |
| Insulation Class | Class F |
| Duty | S1 (continuous) |
| Motor Bearing | C&U |
| Flange Size | 87/61mm or 75/90mm |
Overall Dimensions
Technical Specifications
| Model | Power | Speed (RPM) | Efficiency | Current (A) | Weight (kg) | Voltage (V) | Starting Current (A) |
|---|---|---|---|---|---|---|---|
| Single Phase 50Hz/2-pole | |||||||
| HSL90L1-2 | 2.5HP/1.8KW | 2850 | 0.95 | 65 | 50 | 230 | 12.7 |
| HSL90L2-2 | 3HP/2.2KW | 2840 | 0.99 | 72 | 60 | 400 | 13.4 |
| HSL100L2 | 3HP/2.2KW | 2850 | 0.96 | 74 | 85 | 400 | 15.3 |
| HSL132S1-2 | 5.5HP/4KW | 2920 | 0.88 | 86 | - | 400 | 21.8 |
| HSL132M2-2 | 20HP/15KW | 2920 | 0.87 | 89.2 | - | 400 | 41 |
| Three Phase 50Hz/2-pole | |||||||
| HS90L1-2 | 3HP/2.2KW | 2820 | 0.86 | 78 | - | 400 | 4.9 |
| HS90L2-2 | 4HP/3KW | 2820 | 0.80 | 83 | - | 400 | 8.6 |
| HS100L1-2 | 4HP/3KW | 2840 | 0.83 | 81 | - | 400 | 6.6 |
| HS100L2-2 | 5.5HP/4KW | 2850 | 0.86 | 84 | - | 400 | 11.6 |
| HS132S1-2 | 7.5HP/5.5KW | 2900 | 0.86 | 84 | - | 400 | 15.4 |
| HS132M2-2 | 20HP/15KW | 2920 | 0.88 | 86 | - | 400 | 28 |
| Three Phase 50Hz/4-pole | |||||||
| HS90L1-4 | 2HP/1.5KW | 1400 | 0.82 | 78 | - | 400 | 3.2 |
| HS90L2-4 | 3HP/2.2KW | 1400 | 0.80 | 81 | - | 400 | 6.9 |
| HS100L1-4 | 3HP/2.2KW | 1420 | 0.80 | 81 | - | 400 | 5.1 |
| HS112M1-4 | 4HP/3KW | 1420 | 0.80 | 82 | - | 400 | 12.4 |
| HS132S1-4 | 7.5HP/5.5KW | 1430 | 0.90 | 85 | - | 400 | 17.8 |
| HS132M2-4 | 15HP/11KW | 1430 | 0.90 | 87 | - | 400 | 26 |
| HS160M1-4 | 20HP/15KW | 1450 | 0.86 | 89 | - | 400 | 29 |
